安裝調試快速卷簾門時，需要在安裝精度、電氣系統、裝置等多個方面加以注意，以下是具體問題：

When installing and debugging fast rolling shutter doors, attention should be paid to installation accuracy, electrical systems, safety devices, and other aspects. The following are specific issues:

安裝方面

Installation aspect

水平與垂直度

Horizontal and Vertical

導軌安裝必須保證垂直，誤差應控制在極小范圍內，否則門簾在升降過程中容易出現卡頓、跑偏現象，甚可能導致門體損壞。

The installation of the guide rail must ensure verticality, and the error should be controlled within a very small range. Otherwise, the door curtain is prone to jamming, deviation, and even damage during the lifting process.

卷軸要安裝水平，確保門簾在卷起和放下時受力均勻，避免出現門簾傾斜、一邊高一邊低的情況。

The scroll should be installed horizontally to ensure that the door curtain receives even force when rolled up and lowered, avoiding situations where the door curtain tilts and one side is high while the other is low.

連接牢固性

Connection firmness

門簾的各個簾片之間連接要緊密、可靠，防止在使用過程中出現簾片脫落的危險。

The connections between the various curtains of the door curtain should be tight and reliable to prevent the risk of curtains falling off during use.

導軌與墻體、卷軸與支架、電機與卷軸等各部件之間的連接必須牢固，使用的螺栓、螺母等連接件要符合規格要求，并確保擰緊，必要時可采取防松措施。

The connections between the guide rail and the wall, the scroll and the bracket, the motor and the scroll, and other components must be firm. The bolts, nuts, and other connectors used must meet the specifications and be tightened. If necessary, anti loosening measures can be taken.

預留空間

Reserved space

要根據門的尺寸和運行軌跡，在門的上方、兩側和下方預留足夠的空間，確保門在升降過程中不會與周圍的物體發生碰撞。

According to the size and trajectory of the door, sufficient space should be reserved above, on both sides, and below the door to ensure that it does not collide with surrounding objects during the lifting process.

電機、控制箱等設備也需要有合適的安裝空間，便于后續的維護和檢修。

Suitable installation space is also required for equipment such as motors and control boxes to facilitate subsequent maintenance and repair.

調試方面

Debugging aspect

電氣系統

electrical system

檢查電源電壓是否符合快速卷簾門電機的額定電壓要求，電壓過高或過低都可能影響電機的正常運行，甚損壞電機。

Check if the power supply voltage meets the rated voltage requirements of the fast rolling shutter door motor. High or low voltage may affect the normal operation of the motor and even damage it.

確保電機的接線正確，相序無誤，避免電機反轉。同時，要檢查電線的連接是否牢固，有無松動、虛接等情況，防止出現短路、斷路等電氣故障。

Ensure that the wiring of the motor is correct, the phase sequence is correct, and avoid motor reversal. At the same time, it is necessary to check whether the connection of the wires is firm, whether there is looseness, virtual connection, etc., to prevent electrical faults such as short circuits and open circuits.

運行速度

running speed

調試門的開啟和關閉速度，使其符合使用需求和標準。速度過快可能會對人員和物體造成傷害，速度過慢則會影響使用效率。

Adjust the opening and closing speed of the door to meet usage requirements and safety standards. Too fast speed may cause harm to personnel and objects, while too slow speed can affect usage efficiency.

觀察門在運行過程中速度是否均勻，有無突然加速或減速的現象，如有異常，需要及時調整。

Observe whether the speed of the door is uniform during operation, and whether there is any sudden acceleration or deceleration. If there is any abnormality, it needs to be adjusted in a timely manner.

限位設置

Limit setting

精確調整上下限位開關的位置，確保門在上升到位置和下降到位置時能夠準確停止，避免門體沖頂或撞地，造成設備損壞。

Accurately adjust the position of the upper and lower limit switches to ensure that the door can accurately stop when it rises to the highest position and falls to the lowest position, avoiding the door body from hitting the top or the ground, causing equipment damage.

在設置限位后，要進行多次測試，檢查限位的準確性和可靠性，防止出現限位失靈的情況。

After setting the limit, multiple tests should be conducted to check the accuracy and reliability of the limit, in order to prevent limit failure.

裝置

Safety device

對紅外感應裝置進行調試，檢測其感應范圍和靈敏度，確保在有物體或人員進入感應區域時，門能夠及時停止關閉或重新打開。

Debug the infrared sensing device, test its sensing range and sensitivity, and ensure that the door can stop closing or reopen in a timely manner when an object or person enters the sensing area.

測試氣囊的功能，當門在關閉過程中觸碰到障礙物時，氣囊應能及時觸發，使門立即反向運行。

Test the function of the airbag. When the door touches an obstacle during the closing process, the airbag should be able to trigger in a timely manner, causing the door to immediately reverse.

噪音和振動

Noise and vibration

門在運行過程中應盡量保持低噪音和低振動。如果出現異常的噪音或振動，可能是部件安裝不牢固、潤滑不良或軌道有異物等原因引起的，需要及時排查并解決。

The door should maintain low noise and vibration as much as possible during operation. If there is abnormal noise or vibration, it may be caused by loose component installation, poor lubrication, or foreign objects on the track. It needs to be promptly investigated and resolved.

檢查電機、傳動裝置等部件的運行聲音是否正常，有無摩擦、碰撞等異常聲響。

Check if the operating sound of the motor, transmission device and other components is normal, and if there are any abnormal sounds such as friction or collision.
