相信大家在使用卷簾門的時候都會遇到同樣的一個問題，就是卷簾門遙控器怎樣配。常用的卷簾門遙控器一般分為發射和接收兩個部分。下面濟南卷簾門小編來講講關于遙控卷簾門遙控器的相關事項吧。

I believe that everyone will encounter the same problem when using the roller shutter door, that is, how to match the remote controller of the roller shutter door. The commonly used remote controller for roller shutter door is generally divided into two parts: transmitting and receiving. Now let's talk about the matters related to the remote control of the roller shutter door.

就卷簾門遙控器的接收部分來看，可以分為超外差和超再生兩種方式。超再生解調電路也被稱為超再生檢波電路，實際上就是在間歇振蕩狀態下的再生檢波電路．

As far as the reception part of the roller shutter remote controller is concerned, it can be divided into two modes: superheterodyne and super regeneration. Super regenerative demodulation circuit is also called super regenerative detection circuit, which is actually a regenerative detection circuit under intermittent oscillation

卷簾門遙控器配置中常用的載波頻率為433mHz和315mHz，遙控器使用的載波頻率是規定的開放頻段，在這一頻段內，發射功率小于10mW和覆蓋范圍小于100m，只要不超過本單位范圍，都不必經過“無線電管理委員會”審批可以自由使用。

The common carrier frequencies used in the configuration of the roller shutter door remote controller are 433mHz and 315mHz. The carrier frequencies used in the remote controller are the open frequency band specified by the state. In this band, the transmission power is less than 10mW and the coverage is less than 100m. As long as it does not exceed the scope of the unit, it can be freely used without the approval of the "Radio Management Committee".

在卷簾門遙控器的配置上可以分為紅外遙控器和無線遙控器，它們是由于不同的載波來說的，紅外遙控器是利用紅外線來進行傳送控制信號的，特點是具有方向性、中間不能有阻擋、距離一般都不會超過7米、同時不會受電磁干擾，電視機遙控器采用的比較多的就是紅外遙控器。

In terms of the configuration of the roller shutter door remote controller, it can be divided into infrared remote controller and wireless remote controller. They are due to different carriers. The infrared remote controller uses infrared to transmit control signals. It is characterized by directionality, no blocking in the middle, the distance generally does not exceed 7 meters, and it is not subject to electromagnetic interference. The infrared remote controller is widely used in TV remote controllers.

配卷簾門遙控器操作方法

Operating method of remote controller equipped with roller shutter door

1、清碼

1. Clear code

同時按下遙控器上排的兩個按鍵指示燈閃一次后約2秒后快閃即表示成功。之后按遙控器四個按鍵指示燈僅閃一下后熄滅。

Press the two buttons on the upper row of the remote control at the same time, and the indicator lights flash about 2 seconds later, indicating that the removal is successful. After clearing, press the four buttons on the remote control to turn off the indicator after flashing once.

2、對拷

2. To copy

將原遙控器與對拷遙控器并排擺放（右手拿快拷遙控器），同時按下兩個遙控器任意按鍵，對拷型遙控器指示燈快閃即表示復制成功。僅1秒即可復制成功。依次按相同方法，將其它三個按鍵對拷上。

Place the original remote control and the copy remote control side by side (hold the copy remote control with the right hand), press any key of the two remote controls at the same time, and the copy remote control indicator flashes to indicate that the copy is successful. The copy is successful in only 1 second. Press the same method in turn to copy the other three keys.

3、恢復

3. Restore

若誤操作掉有用代碼后，在沒有重新拷貝其他遙控器之前可同時按下遙控器下排兩個按鍵2秒后指示燈快速閃爍則恢復。

If the useful code is cleared by misoperation, the indicator lamp will flash quickly after pressing the two buttons on the lower row of the remote controller for 2 seconds before copying other remote controllers again.

一般在安裝卷簾門的時候是配備遙控器的，也可以單獨安裝遙控器，這些小常識可以多參考一下的。對于了解配卷簾門遙控器這個問題有很好的幫助，希望能讓大家有所了解。關注我們http://m.wurkt.com，了解更多！

Generally, remote control is equipped when installing roller shutter doors, or it can be installed separately. You can refer to these tips. It is very helpful to understand the problem of remote control for roller shutter door, and I hope it can let you know something about it. Follow us http://m.wurkt.com , learn more!
